G4R25M20P1/4-90
Data
| Product number | G4R25M20P1/4-90 |
|---|---|
| Channel number | 4ch. |
| Lens position | middle |
| Lens spacing | 250μm |
| Lens length | 1/4P(2/4P is available) |
| Lens diameter |
200μm NA=0.2 |
| End face angle | 90 degrees |
